What is a masked version? Mask plate is the carrier of intellectual property information such as graphic design and process technology through graphic transfer tool or master plate in microelectronics manufacturing process. Mask version is also called photomask, photomask, photolithography mask version, mask version, etc. Mask version is widely used in electronic products, home appliances, automobiles and other industry fields, where the main customers are semiconductor manufacturers Intel, Samsung, TSMC and BOE, Huaxing Optoelectronics and other well-known enterprises.

Mask version is divided into two parts: substrate and masking film. As one of the manufacturers of etching process, Zhuolida has successfully practiced various mask version etching needs of customers, so what is the production process of mask version?

1．After the customer determines the graphics, the secondary editing and processing is done by the professional design software.

2．Design data layering based on layout. Calculation, determination and format transformation of the corresponding parameters according to the process requirements.

3．The mask plate is manufactured using a positive photoresist, which is cross-linked inside the lithography of the exposed area by the action of the laser in the photolithography machine.

4．The unexposed area is retained and the film layer is protected by the action of the developer after exposure.

5．The part of the protective film layer will retain the pattern of the graphic, and then dissolve by etching solution for forming.

6．After the dissolution and molding, the excess photoresist is then removed through a demolding process to remove the demoulding solution.

7．Wash both sides of the mask plate with water to remove contaminants.

8．After completing the above steps, dimensional measurements are then performed to obtain the exact parameter values.

9．The next step is to test whether the mask version of the product meets the customer's custom requirements, and to fully inspect and confirm the good quality of graphics, ranking, scars, graphic edges, etc.

10．The good products are packed, sealed and labeled with various parameter values, batches, quantities, etc. for final shipment.
